EVX - Pushing Boundaries
The EVX series HDMI cables combine optimal manufacturing techniques with premium materials and engineering know how to produce stunning results. The award winning series is designed for the true enthusiast, achieving the maximum ‘High Speed with Ethernet’ rating over all lengths using a totally passive design, without electronic compensation.
Construction is based on optimized flat-cable geometry with large gauge solid OFC (Oxygen free copper) conductors, 7% silver plating on the critical TMDS channels and our precision ultrasonic auto soldering. The connector is also precision engineered, offering full alloy shielding and tight tolerances for a secure fit.
Available in seven lengths from 0.5m - 10m, the EVX series maintains ‘High Speed with Ethernet’ compliance
throughout, supporting all the latest formats such as Ultra HD/4K video and 3D.
Lastly every single EVX cable is tested post-production at real world B.E.R (Bit Error Rate) your assurance of
dependable quality.
Technical
- Flexible, flat-profile cables allow reduced skew and shallow mounting depth
- High gauge solid-core OFC (Oxygen free copper) with 7% silver plating on the critical TMDS conductors for high performance
- Ultra HD/4K video and HD Audio from 0.5m to 10m
- Supports Full HD 1080p/60 and 3D across all lengths
- B.O.S.S. termination for consistent and reliable signal integrity
- Ultra-sonic automatic soldered free-air terminals create reduced capacitance and digital jitter for consistently high data rate support
- SureFit™ gold plated die-cast connector fits firmly into HDMI receptacle without falling out
- 2kg retention force
- Full assembly 3-piece shell including 100% internal alloy shield
- Ethernet and Audio return channel
- HDMI compliant
Models
| Length | AWG | Model | Performance |
|---|---|---|---|
| 0.5m | 26 | EVX-HD0050 | High Speed with Ethernet |
| 1.0m | 26 | EVX-HD0100 | High Speed with Ethernet |
| 2.0m | 26 | EVX-HD0200 | High Speed with Ethernet |
| 3.0m | 26 | EVX-HD0300 | High Speed with Ethernet |
| 5.0m | 26 | EVX-HD0500 | High Speed with Ethernet |
| 7.5m | 24 | EVX-HD0750 | High Speed with Ethernet |
| 10.0m | 24 | EVX-HD1000 | High Speed with Ethernet |
